Sensitive equipment needs protection, and since 1976 the answer has been the Pelican™ Protector Case. These cases are designed rugged, and travel the harshest environments on earth. Against the extreme cold of the arctic or the heat of battle, Pelican cases have survived. Made in the USA, these tough cases are designed with an automatic purge valve, that equalizes air pressure, a watertight silicone O-ring lid, over-molded rubber handles and stainless steel hardware.
  • Specifically designed in conjunction with Fire department and EMS personnel
  • Top lid opens up to 180° for on-the-field anti-roll stability when open
  • Lockable compartment for controlled substances
  • Each tray has an overall internal dimension of: 17" x 7.65" x 1.36" (43.18 x 19.43 x 3.45cm) LxWxD
  • Sharps storage bracket included
  • Open cell core with solid wall design - strong, light weight
  • Easy open double-throw latches
  • Stainless steel hardware and padlock protectors
  • Automatic pressure equalization valve - balances interior pressure, keeps water out
  • Adjustable tray dividers allow for easy customization
  • O-ring seal for dust and water resistant seal (IP66)
  • *Sharps container not included
  • Also available without EMS Organizer and Dividers
  • Personalized nameplate service available
  • Lifetime Guarantee of Excellence (Tray system not covered by lifetime warranty)

Details

Military-Grade Protection

Our Protector cases have been designed to meet rigorous US/NATO mil-spec certifications, including an IP67 rating.

Double Throw Latches

Ultra-reliable double-throw latches hold tight under extraordinary drops and impact.

Waterproof, Dustproof, Crushproof

Built to protect your gear against the harshest conditions

Measurements

Exterior

(LxWxD)


Inches: 20.85 x 12.73 x 12.75 in

Centimeters: 52.96 x 32.33 x 32.39 cm

Padlock Hole Diameter: 5/16"


Interior

(LxWxD)


Inches: 18.54 x 9.92 x 10.92 in

Centimeters: 47.09 x 25.2 x 27.74 cm


Capacity

Volume: 58.6QT (55.46 liters)

Int Volume: 1.16 ft³ (0.03 m³)

Lid Depth: 4.91" (12.5cm)

Bottom Depth: 6.01" (15.3cm)

Total Depth: 12.75" (32.4cm)

Materials

Foam Material: Polyurethane

Body Material: Polypropylene

Latch Material: EXL

O-Ring Material: Polymer

Pins Material: Stainless Steel

Purge Body Material: ABS


Temperatures

Min Temp: -40°F

Max Temp: 210°F

Warranty

Guarantee of Excellence
